SPR-RP1300A Basic Planer Sander

SPR-RP1300A Basic Planer Sander

The SPR-RP1300A Basic Planer Sander is an innovative and high-performance solution designed for woodworking professionals and enthusiasts alike. As an essential tool in the woodworking process, this machine offers unparalleled precision, efficiency, and reliability. With its advanced features and robust construction, the Basic Planer Sander is engineered to meet the demands of both commercial and industrial applications.

Design and Construction

The SPR-RP1300A showcases a modern design that prioritizes functionality while maintaining a user-friendly approach. With an overall dimension of 2110mm in length, 3020mm in width, and 2500mm in height, its compact footprint belies the expansive capabilities nestled within. Weighing in at 7200kg, this planer sander is built solidly to withstand rigorous use, ensuring long-term durability and stability even during high-speed operations.

At the core of the SPR-RP1300A is an advanced sanding mechanism that guarantees remarkable results with every pass. The machine can handle materials up to 1300mm in width and a minimum length of 580mm, accommodating a range of workpieces. Whether your projects involve large sheets or smaller components, this planer sander provides the versatility to adapt to your needs.

Technical Specifications

The SPR-RP1300A is equipped with powerful motors for unparalleled efficiency:

• Total Power

  Boasting a total power output of 79 kW, including:

  • Motor for 1st Unit: 30 kW
  • Motor for 2nd Unit: 22 kW
  • Motor for 3rd Unit: 22 kW
  • Feeding Motor: 4 kW
  • Lifting Motor: 0.75 kW
  • Motor for Brush Roller: 0.37 kW

  No.	Item	Data	No.	Item	Data
  1	Work width MAX. (mm)	1300	10	Total Power (kw)	79
  2	Work length MIN. (mm)	580	11	Motor for 1st Unit (kw)	30
  3	Working Thickness (mm)	10-160	12	Motor for 2nd Unit (kw)	22
  4	Feeding speed (m/s)	5-30	13	Motor for 3rd Unit (kw)	22
  5	Shore of shaft (sh)	Planer/80sh/55sh	14	Feeding Motor (kw)	4
  6	Diameter of shaft (mm)	Φ180/φ240/φ210 +pad	15	Lifting Motor (kw)	0.75
  7	Abrasive Belt Size (mm)	1330×2200	16	Motor for Brush Roller (kw)	0.37
  8	Volume of Dust Collection Device (m³/h)	16786	17	Overall dimension (mm)	2110×3020×2500
  9	Voltage	380V/50HZ/3PH	18	Net Weight (kg)	7200

The combination of these motors allows the sander to achieve a working thickness range from as thin as 10mm to as thick as 160mm. The adjustable feeding speed ranging from 5 to 30 m/s ensures that you can tailor the sanding process to the specific characteristics of each material.

The abrasive belt, measured at 1330mm x 2200mm, facilitates effective and efficient sanding, making quick work of even the toughest surfaces. The system employs a robust shore hardness specification of Planer 80sh and 55sh, ensuring that it maintains peak performance throughout its operational lifespan.

Performance and Features

The SPR-RP1300A is built for speed and precision, enabling operators to achieve smooth and flawless finishes consistently. Its key features include:

1. Versatile Thickness Adjustment: With the capacity to sand materials ranging from 10 to 160mm, this machine is suitable for a diverse array of projects, from bespoke cabinetry pieces to large-scale industrial finishes.
2. High-Volume Dust Collection: Equipped with an impressive dust collection capacity of 16786 m3/h, the SPR-RP1300A safeguards the working environment, ensuring cleaner operations and enhanced visibility while working.
3. User-Friendly Control Panel: The sander is equipped with a state-of-the-art control panel that simplifies machine operation and provides real-time feedback. This feature allows for easy adjustments to speed, power, and thickness settings, ensuring efficiency and maintaining optimal results.
4. Robust Feeding Mechanism: The feeding system, with adjustable tension and precision rollers, keeps materials firmly in place as they pass through the sanding process. The quick-release mechanism enables easy swaps between different material types or sizes, minimizing downtime.
5. Durable Construction: The high-quality materials used in construction, combined with rigorous testing, ensure the lightweight but rugged design can endure the wear and tear of day-to-day operations.

Applications

This Basic Planer Sander is exceptionally versatile, ideal for a wide range of applications, including but not limited to:

• Woodworking Shops: Perfect for cabinetry, furniture manufacturing, and custom designs.
• Industrial Settings: Suitable for larger-scale operations that require efficient material processing and finishing.
• Hobbyist Workshops: For woodworkers looking to elevate their craft with professional-grade equipment.
• Commercial Furniture Production: Reliable for high-volume production that requires consistent and high-quality surface finishes.

Ease of Maintenance

The SPR-RP1300A has been designed with maintenance in mind. Accessing critical components for servicing and repairs is straightforward thanks to the thoughtfully engineered layout. Regular upkeep is simplified with clear maintenance guidelines and an accessible manual that comes with the machine. This ensures that operators can easily conduct periodic checks, enhance machine performance, and extend equipment longevity.

Safety Features

Safety is a top priority in the design of the SPR-RP1300A Basic Planer Sander. Several built-in features promote secure operation:

• Emergency Stop Button: Located within easy reach, the emergency stop function ensures immediate halting of the machine in case of an emergency, safeguarding operators and materials.
• Safety Guards: High-quality protective shields prevent accidental contact with moving components, ensuring a safer work environment.
• Overload Protection: This system helps prevent equipment damage by automatically shutting down if conditions exceed established parameters, extending the lifespan of the machine.

Conclusion

The SPR-RP1300A Basic Planer Sander stands out as an essential addition to any woodworking setup, whether for professional craftsmen or dedicated hobbyists. Its impressive technical specifications, innovative features, and durable build make it a reliable tool that guarantees optimal performance.

Invest in the SPR-RP1300A to elevate your woodworking experience, and enjoy the power, precision, and reliability this planer sander offers. With its diverse applications and user-friendly operation, it’s the perfect machine to bring your woodworking visions to life.

Elevate your craftsmanship today with the SPR-RP1300A Basic Planer Sander—where technology meets artistry in the world of woodwork!
