ITEM-45X CNC Sliding Table Saw

ITEM-45X CNC Sliding Table Saw

Introduction

Introducing the LK-Tech ITEM-45X CNC Sliding Table Saw, the epitome of precision, efficiency, and automation in woodworking machinery. As an industry leader, K-Tech has engineered this panel saw with state-of-the-art technology designed to meet the diverse demands of modern woodworking. Whether you are working in a commercial shop or managing a small-scale craft business, this powerful tool will be your ultimate companion for producing high-quality cuts with impeccable accuracy.

Key Features

1. Advanced Sliding Table System

The ITEM-45X features an impressively designed sliding table that measures 3,200 mm (with a cutting capacity of up to 3,100 mm). This elongation allows for substantial material support, ideal for handling large sheets of different materials such as plywood, MDF, laminated board, and solid wood. The robust construction provides stability and prevents vibration during operation, ensuring a smooth and precise cutting performance.

2. High-Performance Carriage Seat Design

The carriage seat boasts an extraordinary cutting width of 1,300 mm. Users can enjoy a moving speed of 250 mm/s, optimizing workflow and efficiency. Accuracy is never compromised with a tolerance of +/- 0.1 mm. The built-in ending safety sensors enhance user safety, while the data auto-correction feature guarantees that the machine adjusts accordingly, securing accurate measurements at all times.

3. Versatile Cross Baffle for Extended Capabilities

The ITEM-45X is equipped with a manually adjustable cross baffle that accommodates a cutting width of up to 3,200 mm. This feature integrates a high-quality magnifying glass and clear ruler to enhance usability, allowing operators to measure cuts with ultimate perfection. This versatility caters to both straight cuts and intricate designs, making it a multifunctional tool suited for various project needs.

4. Digital Touch Screen Control Panel

The control panel of the ITEM-45X is designed for user-friendly interaction. Featuring a digital touch screen integrated with a servo motor system, operators can effortlessly navigate through settings and commands. This intuitive interface provides real-time data and feedback, allowing for quick adjustments and enhancing overall operational efficiency.

5. Exceptional Motor Power and Cutting Speed

Equipped with a high-performance main saw motor rated at 6.5 kW, the ITEM-45X is designed to handle even the most demanding projects. The saw center hole diameter is 30 mm, with an adjustable speed range of 4,000-5,000 RPM. The saw blade angle is adjustable between 0° and 45°, allowing users to create bevel cuts with ease. The diverse saw size compatibility ranging from 100 mm to 350 mm gives woodworkers the flexibility to execute a range of cutting tasks.

6. Innovative Groove Saw Feature

In addition to its main saw capabilities, the ITEM-45X includes a groove saw with a motor power of 1.1 kW, specifically designed to create grooves and channels with unparalleled precision. Operating at 8,200 RPM and a center hole diameter of 20 mm, the groove saw is perfect for creating joints, dados, and other intricate cuts that are vital in furniture making and cabinetry work.

7. Effective Dust Management with Safety Features

The ITEM-45X is designed with the operator’s safety in mind. It features a comprehensive dust cover (CFD) that ensures a cleaner workspace by effectively managing sawdust and debris during operation. This integration doesn’t just enhance visibility but also boosts the lifespan of the machine by preventing dust accumulation in critical components.

8. Built for Durability and Reliability

Built from high-quality materials, the K-Tech ITEM-45X is engineered for flexibility and durability. Whether for intensive daily usage or sporadic hobbyist projects, this machine’s sturdy construction withstands the rigors of any woodworking environment.

Specifications

ITEM-45X Specifications
CNC Sliding Table Saw L3200mm (cutting at 3100mm)
Carriage Seat Cutting width 1300mm, moving speed 250mm/s
Accuracy +/-0.1mm
Safety Features With ending safety sensors
Data Handling Data auto correction
Cross Baffle Cutting width 3200mm, manual
Measurement With high quality magnifier and ruler
Control Panel Digital touch screen control system with Servo motor
Main Saw Power 6.5kw, Center hole Diameter 30mm
Main Saw Speed 4000~5000 rpm
Main Saw Range Degree 0-45°, Saw size 100~350mm
Groove Saw Motor power 1.1kw, Center hole 20mm
Groove Saw Speed 8200rpm
Dust Management Dust cover CFD

Applications

The versatility of the K-Tech ITEM-45X makes it suitable for a variety of applications within the woodworking industry, including but not limited to:

  • Furniture Manufacturing: Create intricate designs and precise cuts for tables, chairs, cabinets, and more.
  • Cabinetry: Produce high-quality cabinetry with clean edges and smooth finishes.
  • Architectural Woodworking: Ideal for producing elements required in architectural projects, including molding and custom fitting.
  • DIY and Hobby Work: Perfect for enthusiasts looking to create custom wood projects in a home or garage workshop.

Conclusion

The K-Tech ITEM-45X CNC Sliding Table Saw is the perfect solution for those seeking quality, performance, and precision in their woodworking tools. Backed by advanced technology and user-oriented features, it stands ready to tackle the challenges of modern woodworking. Whether you’re a seasoned professional or just starting your journey in woodworking, the ITEM-45X will elevate your craftsmanship to new heights, enabling you to deliver products that meet the highest standards of quality. Invest in the ITEM-45X, and let your creative visions come to life with unmatched efficiency and accuracy.

Don’t miss out on revolutionizing your woodworking experience with the K-Tech ITEM-45X CNC Sliding Table Saw – the ultimate choice for precision cutting in woodworking!
